Fence Paint Calculator

Use this free fence paint calculator to instantly calculate how many gallons of paint, stain or sealer you need for any fence. Enter your fence length, height and style, and the calculator applies the surface area factor for your fence type (privacy, picket, split rail, shadowbox, lattice or stockade), adjusts for sprayer overspray, and estimates material and labor cost. Quick answer: a 100 ft, 6 ft privacy fence painted on one side needs about 2 gallons per coat, or about 4 gallons for two coats if you roll. See the table by fence length.

AI-generated illustration of a weathered wooden backyard fence beside paint cans, a roller and a tape measure
Illustration created with AI for this page. It is not a photo of a real fence.
Reviewed by · Published: March 24, 2026 · Updated: October 30, 2026 · Sources: Behr · YellaWood · Angi · Lowe’s
Fence Paint Calculator
📐 Formula Used
Surface Area = Length × Height × Style Factor × Sides
Gallons = (Surface Area ÷ Coverage per Gallon) × Coats
Coverage varies: solid stain ~150 sq ft/gal · semi ~200 sq ft/gal · clear ~250 sq ft/gal
Paint / Stain Needed
0 gallons
Enter fence dimensions above to calculate
Surface Area
0 sq ft
Gallons per Coat
0 gal
Material Cost
—
Total Cost (incl. labor)
—

Privacy fence needs ~150 sq ft/gal (solid surface) · Picket fence needs more due to edges · A sprayer uses more paint than a brush or roller (this calculator adds 38%) · Always buy 10% extra

Prices are planning ranges, not quotes. Coverage varies by product brand, wood porosity, and condition. Always check the product label for actual coverage rates and get a local quote before you buy.

How Does the Fence Paint Calculator Work?

✅ Quick Answer

A 100 ft long, 6 ft tall privacy fence painted on one side needs about 2 gallons of exterior paint per coat (600 sq ft ÷ about 350 sq ft per gallon). For two coats plus 10% extra, buy 4 gallons if you roll and about 6 gallons if you spray. Picket and shadowbox fences need more, and split rail needs much less. See the table by fence length below.

This fence paint calculator estimates gallons of paint, stain, or sealer needed for any fence — accounting for fence style (privacy vs picket vs split rail), number of coats, sides painted, and application method. It calculates both material cost and total project cost including labor.

The key difference from a simple wall paint calculator is fence style factor. A picket fence has many exposed edges and gaps that consume significantly more paint than a flat privacy fence of the same length. A split rail fence uses far less paint because most of the wall area is open sky. This calculator accounts for all of these differences automatically.

💡 Sprayer Uses More Paint Than You Think

An airless sprayer is the fastest way to paint a long fence. However, a sprayer uses more paint than a brush or roller because of overspray and the paint left in the hose and pump. Lowe’s makes the same point in its sprayer guide. Published estimates vary widely: one professional painter reports 33% to 100% more paint with an airless sprayer, based on his own experience. This calculator adds 38% as a middle planning value, so use a roller or brush setting if that is how you will paint. Cover plants, pavers and nearby structures before spraying, and skip windy days, because overspray drifts.

🔗 Which Fence Tool Do You Need?

This calculator sizes your paint or stain order — gallons needed and material cost, based on fence style and application method. If you want a full project cost estimate that also factors in fence condition (weathered vs. good), prep/power washing, and a DIY vs. contractor labor comparison, use the Fence Staining Cost Calculator instead — the two are built to answer different questions.

How Much Paint Do I Need for a Fence?

The table shows gallons of exterior latex paint for a 6 ft tall privacy fence, one side, two coats, plus 10% extra. It uses the same numbers as the calculator: 350 sq ft per gallon, with 38% more paint when spraying. Round to whole gallons when you buy.

Fence LengthSurface AreaRoller / BrushAirless Sprayer
25 ft150 sq ft1 gal2 gal
50 ft300 sq ft2 gal3 gal
100 ft600 sq ft4 gal6 gal
150 ft900 sq ft6 gal8 gal
200 ft1,200 sq ft8 gal11 gal
300 ft1,800 sq ft12 gal16 gal

For both sides, double the gallons. For a picket, shadowbox, lattice or split rail fence, multiply the surface area by the style factor in the fence style table first. For stain, divide by the stain’s coverage instead of 350. Product labels list their own range: for example, Behr says one gallon of its exterior paint covers 250 to 400 sq ft with one coat, and rough or unpainted surfaces use more.

Paint vs Stain vs Sealer — Which Should You Use?

Choosing the right product is the most important fence finishing decision. Each product type offers different protection levels, appearances, and recoat schedules.

ProductCoverage/GalLifespanRecoat EveryBest For
Exterior Paint (latex)300–400 sq ft5–10 yrs5–7 yrsColor, full coverage, vinyl-look finish
Oil-Based Paint / Primer250–350 sq ft7–12 yrs7–10 yrsRaw / bare wood, best adhesion
Solid Stain150–200 sq ft4–7 yrs3–5 yrsColor with wood texture showing
Semi-Transparent Stain200–300 sq ft3–5 yrs2–4 yrsNatural wood color, grain visible
Clear / Transparent Stain250–350 sq ft2–4 yrs1–3 yrsNatural wood, maximum grain show
Water Repellent Sealer200–300 sq ft1–3 yrs1–2 yrsCedar, redwood — preserve natural look

Coverage, lifespan and recoat times are planning rules of thumb, not warranties, and they vary with climate, sun exposure and wood. Labels differ: Behr lists 200–400 sq ft for the first coat of its solid-color fence stain. This calculator uses lower values for rough fence boards (350 for paint, 150 for solid stain) so that you do not run short.

⚠ Check New Pressure-Treated Wood Before You Finish It

New pressure-treated (PT) lumber can be too wet to hold paint or stain, and finish applied to wet wood can peel. The old advice was to wait six months to a year, but YellaWood says that rule no longer applies to newer treatments and that its wood can be stained within about six weeks if it is dry enough. Do the water test: sprinkle a few drops on the boards. If the water beads, wait several days and test again. If it soaks in, the wood is ready. Check your lumber tag or the manufacturer’s instructions.

Fence Style Coverage Guide

Different fence styles have dramatically different paint coverage requirements due to exposed edges, gaps, and board spacing. Here's how each style compares for a 100 linear ft of 6 ft fence.

Fence StyleSurface Area (100 LF × 6 ft)Style FactorWhy It Differs
Privacy / Board-on-Board600 sq ft1.0×Solid surface, flat face
Stockade620 sq ft1.03×Tight pickets, minimal gaps
Shadowbox720 sq ft1.2×Alternating boards — both sides visible
Picket750 sq ft1.25×Many exposed edges add significant surface
Lattice Top800 sq ft1.33×Lattice section has massive edge exposure
Split Rail200 sq ft0.33×Very open — only the rails themselves
💡 The Picket Fence Multiplier

Picket fences use 25% more paint than flat privacy fences of the same height and length — because every picket has two long edges plus a top and bottom edge that all need to be coated. If you're painting a picket fence with a brush, coat all four sides of each picket individually. With a sprayer, make multiple passes from slightly different angles to ensure full edge coverage.

Application Method Guide

MethodSpeedPaint UsageCoverage QualityBest For
Airless SprayerVery fastUses more (about 38% in this calculator)Good (may miss edges)Privacy, large projects, solid stain
Roller + BrushModerateMost efficientBest — thorough coverageMost fences — best all-around
Brush OnlySlowEfficientExcellent on edgesPicket fences, touch-ups, small runs
Pad ApplicatorModerateEfficientGoodFlat smooth fences, staining

Professional Recommendation:

For a wood privacy or shadowbox fence, the best DIY approach is to spray first, back-brush second. Spray one coat with an airless sprayer for speed, then follow immediately with a brush to work the paint into gaps and joints before it dries. This gives you both speed and thorough coverage. It uses more paint than brushing alone but less than two full spray coats.

Fence Paint & Stain Cost

ProductCost per GallonCoverage/Gal100 LF Privacy Fence (1 coat)
Budget Exterior Paint$25 – $40300–350 sq ft$50 – $80
Mid-Range Exterior Paint$40 – $65350–400 sq ft$60 – $110
Premium Exterior Paint$65 – $90350–400 sq ft$100 – $155
Solid Deck Stain$35 – $60150–200 sq ft$105 – $240
Semi-Transparent Stain$30 – $55200–300 sq ft$60 – $165
Clear Sealer$25 – $50250–350 sq ft$43 – $120
Professional Labor——$1.50 – $3.50/LF

The per-gallon prices are planning ranges and include premium products. Angi’s 2025 cost guide lists DIY paint at $20 to $80 per gallon and stain at $20 to $50 per gallon, and total painting or staining costs of $2 to $10 per linear foot for a wood privacy fence (one coat, materials and labor). The labor row above is this calculator’s planning figure for labor alone. These figures assume a fence already in good condition. For a weathered fence needing power washing and prep first, see the condition-adjusted pricing on our Fence Staining Cost Calculator.

Example Calculation

Painting a 150 ft privacy fence, 6 ft tall, exterior latex paint, 2 coats, 1 side, airless sprayer, DIY.

Step 1 — Surface area (privacy, 1 side):

150 × 6 × 1.0 (style factor) = 900 sq ft

Step 2 — Gallons per coat (exterior paint, 350 sq ft/gal):

900 ÷ 350 = 2.57 gallons by roller or brush

Step 3 — Add the sprayer factor (38% more paint):

2.57 × 1.38 = 3.55 gallons per coat

Step 4 — Two coats:

3.55 × 2 = 7.1 gallons

Step 5 — Add 10% extra and round up:

7.1 × 1.10 = 7.8 → buy 8 gallons (a roller needs 6)

Step 6 — Material cost (mid-range paint at about $50/gal):

8 × $50 = ~$400 in paint

Prep & Application Tips

Prep (the Most Important Step)

  • Clean the fence first — pressure wash or scrub with a fence cleaner (TSP or oxalic acid for grey wood). Paint over dirty or mildewed wood can peel early. Let dry completely — at least 48 hours — before painting.
  • Sand rough spots — knock down any raised grain, splinters, or peeling paint. A pole sander makes this fast on long sections.
  • Prime bare or new wood — any bare, unpainted wood sections need a coat of exterior primer before topcoat. Skipping primer on bare wood can lead to early peeling.
  • Caulk post bases — seal where fence boards meet posts and where posts meet the ground with exterior caulk to prevent water infiltration.
  • Paint on a dry, mild day — pick a dry day within the temperature range on the label (often about 50–90°F) with no rain forecast for the next day or two. Avoid painting in direct hot sun, which can make paint dry too fast and leave brush marks, and follow the temperature range printed on the can.

Application Tips

  • Work top to bottom — start at the top rail and work downward so drips land on unpainted sections and get covered by the next stroke.
  • Don't overload the brush — dip only the bottom third of the bristles and tap off excess. Overloaded brushes drip and leave runs that need sanding between coats.
  • Protect neighbors and plants — hang plastic sheeting on the neighbor's side before spraying and cover garden beds and shrubs. Stain and paint overspray is nearly impossible to remove from plants.
  • Two thin coats beat one thick coat — thick coats sag, take longer to dry, and peel faster than two thinner coats applied correctly.
✅ Choosing a Product for a Wood Fence

For bare wood, use an exterior primer or a self-priming fence stain, then two thin coats of the finish. Look for products labeled for exterior wood and read the label for coverage, recoat time and surface preparation. Rough boards soak up more finish, so plan for the low end of the coverage range. Brand rankings change, so compare current labels and reviews rather than relying on a single recommendation.

How We Calculate

Surface area = length × height × style factor × sides. Gallons = (surface area ÷ coverage per gallon) × sprayer factor × coats × 1.10. The result is rounded up to whole gallons.

  • Coverage per gallon: 350 sq ft for exterior latex paint, 300 for oil-based paint or primer, 150 for solid stain, 240 for semi-transparent stain, 290 for clear stain and 260 for sealer. These sit inside or below the ranges on manufacturer labels such as Behr’s, so the estimate leans toward buying slightly more.
  • Style factors (picket 1.25, shadowbox 1.20, lattice 1.33, stockade 1.03, split rail 0.33): these are this site’s own planning estimates for exposed edges and gaps. They are not an industry standard. Measure a few boards if your fence is unusual.
  • Sprayer factor 1.38: a middle value in the 33% to 100% extra range that painters report for airless sprayers. Choose roller or brush to remove it.
  • Extra 10%: a buffer for spills, touch-ups and uneven boards.
  • Cost: gallons × the per-gallon price range in the table, plus $1.50 to $3.50 per linear foot for professional labor when selected.

Frequently Asked Questions

How many gallons of paint do I need for a fence?+
A 6 ft privacy fence painted on one side needs about 1 gallon of exterior paint for every 58 linear feet per coat when you roll or brush (350 sq ft ÷ 6 ft), or about 1 gallon per 42 feet when you spray. A 150 ft fence needs about 2.6 gallons per coat by roller. For two coats plus 10% extra that is 6 gallons by roller or 8 gallons by sprayer. See the table by fence length or use the calculator above for your fence style, height and number of coats.
For a 6 ft privacy fence painted on one side, 100 feet is 600 sq ft. That takes about 1.7 gallons per coat of exterior paint at 350 sq ft per gallon. For two coats plus 10% extra, buy 4 gallons if you roll or brush, or 6 gallons if you spray.
Divide the surface area by the stain’s coverage. Labels list ranges, for example 200 to 400 sq ft per gallon for the first coat of one solid fence stain, and rough boards soak up more. This calculator uses 150 sq ft per gallon for solid stain, 240 for semi-transparent and 290 for clear. A 100 ft privacy fence (600 sq ft) needs about 4 gallons of solid stain per coat by those figures.
Not always for six months, as older advice said. YellaWood says newer treatments can be stained within about six weeks if the wood is dry enough. Use the water test: if drops of water bead on the boards, wait a few days and test again. If they soak in, the wood is ready to finish.
Paint lasts longer (5–10 years) and offers full color control but hides the wood grain. Stain penetrates the wood fibers for a natural look and is easier to recoat without stripping, but needs recoating more frequently (2–5 years). For a cedar or redwood fence showing off the natural grain, use a semi-transparent stain. For a pine fence you want to be a specific color, use exterior paint. Avoid clear sealers on pine — they offer minimal UV protection.
Angi’s 2025 cost guide puts painting or staining a wood privacy fence at about $2 to $10 per linear foot for one coat, including materials and labor, and shadowbox fences at $4 to $14. Professional painters often charge $25 to $100 per hour with a minimum job charge. This calculator uses $1.50 to $3.50 per linear foot as a planning figure for labor alone, which you add to the paint cost. DIY costs only materials. Weathered fences need power washing and prep first, so use our Fence Staining Cost Calculator for a condition-adjusted estimate.
As a rule of thumb, quality exterior paint on a properly prepared fence lasts 5 to 10 years, solid stain 4 to 7 years, semi-transparent stain 2 to 5 years and clear sealers 1 to 3 years. These are planning ranges, not warranties. Lifespan depends on sun exposure, climate, wood species and prep. Recoat before the finish fails completely, because a maintenance coat is cheaper than stripping and restarting.
Spraying is much faster but uses more paint because of overspray, and it needs careful masking of everything nearby. Brushing is slower but uses paint efficiently and covers edges well. Many DIYers spray and then back-brush right away to work the paint into gaps. For a picket fence, brushing is often more practical because every picket edge needs coverage. Plan on extra paint if you spray: this calculator adds 38%.
Yes — a 4-inch foam or nap roller works well on flat privacy fence boards, especially for the main faces. Use a brush to follow behind the roller and work paint into joints, gaps, and board edges. A roller alone misses the spaces between boards and won't cover edges properly. For best results on a privacy fence: roll the flat faces, then use a 2–3 inch brush for edges and joints.

Sources and References

The figures and guidance on this page were checked against the sources below in October 2026.

The style factors, the 38% sprayer allowance and the labor rate are this site’s own planning estimates, as explained under How We Calculate. ConstructlyTools does not have a paid relationship with any paint manufacturer, retailer or contractor mentioned on this page.
